Newborn Anne

The Newborn Anne is a manikin designed for skills training in neonatal resuscitation. With anatomical accuracy and product features designed to focus on the critical resuscitation skills required in the first ten minutes of a newborn’s life, Newborn Anne meets the key components of the Neonatal Resuscitation Program and most other neonatal clinical training curricula.

Product Benefits:

• Educational effective allowing specific neonatal resuscitation skills to be taught individually or in combination with other skills.
• Realistic anatomical landmarks and durable design simulate a full-term female newborn.
• Lightweight and portable design allows Newborn Anne to be highly mobile for use in multiple clinical settings.
• Newborn Anne is easy to use and has been designed to be integrated into all neonatal training curricula.
• Built from the SimNewB platform, Newborn Anne has been specifically designed with manikin features that are clinically relevant to acquire the skills in training for neonatal life support.

Product Features:

• Newborn Anne accurately represents a full term (40 week), 50^th percentile newborn female, measuring 21 inches and weighing 7lbs.
• The airway is designed to allow for training in all aspects of newborn airway management, including the use of positive-pressure airway devices, and the placement of ET tubes and LMAs.
• The torso includes functionality to relieve a tension pneumothorax via needle decompression.
• The patent umbilicus has a manually generated pulse and can be assessed, cut and can be catheterized for IV access.
• Newborn Anne features IO access in both legs.

Airway Features

• Positioning the newborn to simulate opening the airway via head tilt, chin lift or jaw thrust
• Positive Pressure Ventilation  (BVM, T-Piece resuscitator, or anesthesia bag)
• ET tube intubation
• LMA insertion
• Orogastric tube insertion
• Stomach distension (when ET is misplaced)
• Suctioning (of the nares, nasopharynx, oropharynx, esophagus and the lungs via an ET tube) - Fluids should not be introduced into the airway
• Meconium module for suction removal

Breathing features

• Bilateral and unilateral (with mainstem intubation) chest rise and fall with mechanical ventilation
• Pneumothorax - Needle thoracentesis left mid axillary (pneumothorax)

Cardiac features

• Manual chest compression at appropriate depth (1/3 AP) and force

Circulation Features

• Manual umbilical pulse

 Vascular Access

• Umbilical Vein/ Artery access via patent umbilicus
• IO access in left and right lower leg, tibial tuberosity and medial malleolus

 Other Features

• Full articulation
